How to use the stopwatch

Standard measurement Ex. 5,000 meters running

8T61_Stopwatch Ex-1 + Stopwatch Ex-1

Start

Stop

Reset

Start the measurement

Goal

Reset the stopwatch to 0 minute 0 second.

Example of measurement:
20 minutes 41 seconds

Button A

Button A

Button B

8T61_Stopwatch Ex-1 V + Stopwatch Ex-1 V

Start

Stop

Reset

Start the measurement

Goal

Reset the stopwatch to 0 minute 0 second.

Example of measurement:
20 minutes 41 seconds

Button A

Button A

Button B

Accumulated elapsed time measurement Ex. Measuring the time for a soccer match

8T61_Stopwatch Ex-2 + Stopwatch Ex-2

Start

Stop

Start

Stop

Reset

Start match.

Stop match.

Start again.

The match ends.

Reset the stopwatch to 0 minute 0 second.

Button A

Button A

Button A

Button A

Button B

Restart and stop of the stopwatch can be repeated.

8T61_Stopwatch Ex-2 V + Stopwatch Ex-2 V

Start

Stop

Start

Stop

Reset

Start match.

Stop match.

Start again.

The match ends.

Reset the stopwatch to 0 minute 0 second.

Button A

Button A

Button A

Button A

Button B

Restart and stop of the stopwatch can be repeated.
