The operation shown in the illustration below toggles between “charge level display” and “stopwatch display”.
Toggling between the displays changes the function of the hands.
<Charge level display>
<Stopwatch display>
Center hand
Energy level hand
Stopwatch 1/5-second hand
Stopwatch minute hand
Button A
Button B
Press and release button A
Press and release button B
<Charge level display>
<Stopwatch display>
Center hand
Energy level hand
Stopwatch 1/5-second hand
Stopwatch minute hand
Button A
Button B
Press and release button A
Press and release button B
On the “charge level display”, press button A to toggle to the “stopwatch display” and simultaneously start the stopwatch.
While the stopwatch is operating, you cannot toggle the display. To return to the “charge level display”, first reset the stopwatch.
During operation of the stopwatch, button B provides “split”, “split reset” and “reset” functions.
On resetting the stopwatch, the display automatically returns to “charge level display” after 1 minute.
